Fox Factory Fox 40 Float Factory Series Fork - 2023-24 - Shiny Black

Fox Factory Fox 40 Float Factory Series Fork - 2023-24 - Shiny Black

Damper Details:
Hub Fitment:
20x110mm Boost
Amount of Travel:
203mm Travel
Shiny Black
Fork Offset:
Release Year:
Steerer Size:
1 1/8th Inch Straight
Wheel Fitment:
29 Inch
← More Options
Rated 5.0 stars
1 Review

Regular price $3,629.95
Regular price Sale price $3,629.95
Sold out
Tax included.


Add to Wishlist

The FOX 40 Float Factory Kashima Fork is now better than ever in terms of performance and control, with an updated version of the FIT GRIP2 damper, an updated EVOL air spring, and a host of other radical new performance-driven features, resulting in a truly remarkable World-Class DH fork.

The FOX Factory Series offers the best of the best technology with low friction performance with the distinctive gold Kashima coating which offers high-performance attributes and properties with low friction seals, all combining to give an exceptionally buttery smooth ride over the world's rowdiest terrain, thanks to its burly 40mm stanchions.

The combined effect of the EVOL Air Spring for optimum small bump sensitivity and the Air Transfer Port system gives you an extremely plush fork with additional mid-stroke support and a more tunable bottom-out progression for a perfect ride set-up.

GRIP2 has been relentlessly tested and proven on the demanding World Cup Downhill circuit by the worlds elite riders and is tuned to deliver the right amount of support without the harshness and adds a level of refinement over the previous generation of dampers.

The FOX 40 Float Factory Kashima Fork is equally at home on the challenging World Cup circuit DH trails to the world's biggest bike parks. A fork that can handle anything you dare to throw at it.

Key Features:

  • GRIP2 damper with 4-way high and low-speed compression, rebound damping and VVC technology.
  • Lower Leg Bypass Channels: Helps alleviate excessive pressure ramping at end stroke by dramatically increasing air volume within the lower legs.
  • Air Bleeders: Air bleed system ensures consistent fork performance at any altitude.
  • Air Spring: FLOAT EVOL's linear spring curve delivers plushness off the top, extra mid-stroke support, and more tunable bottom-out progression.
  • Friction Reduction: Low Friction seals, and coated shaft and tube surfaces.
  • Axle: 20mm floating thru-axle. Floating axles provide much smoother suspension movement throughout the entire range of the fork’s travel, notably improving sensitivity and overall ride quality.
  • Upper Tube Finish: Genuine Kashima Coat
  • Steerer: 1.125
  • Colour: Gloss Orange / Matte Black
  • Starting Weight: *2816 g (* F-S, 40, 27.5", GRIP2 Fork weights are at 200mm steerer length with star fangled nut and disc brake guide installed.)


  • Wheel Size: 27.5” / 29"
  • Recommended Use: Downhill
  • Travel: 203 mm
  • Steerer Options: 1.125 straight
  • Spring: Air - Float EVOL
  • Stanchion: 40mm
  • Adjustments: Rebound / Low-speed compression / High-speed compression / Air spring pressure
  • Rotor Size: 203 direct Post-Mount. Compatible with up to 230mm


  • High-speed compression (w/VVC): 8 clicks
  • Low-speed compression: 16 clicks
  • High-speed rebound (w/VVC): 8 clicks
  • Low-speed rebound 16 clicks
View product description
Rated 5.0 stars
Based on 1 review
Total 5 star reviews: 1 Total 4 star reviews: 0 Total 3 star reviews: 0 Total 2 star reviews: 0 Total 1 star reviews: 0
100%would recommend this product
1 review
  • Jarrod B.
    I recommend this product
    Rated 5 stars
    4 years ago
    Its being 5 years since

    Its being 5 years since ive been on 40's and Fox have nailed it for 2017 they are just truly amazing and performance i rate over my previous BOS Idylle's.

Reviews LoadedReviews Added
