Level Ultimate Stealth 4 Piston Disc Brake

For the first time ever, SRAM’s legendary Code brake now wears the Ultimate crown. The full-powered stopper features a new technology to improve your cockpit aesthetic: Stealth. The all-new lever body design brings the hose closer to the bar, allowing for a sleeker, more modern ride. The proven internals remain the same, with SwingLink driving SRAM’s signature feel. And for unrivalled ease of customization, Code Ultimate features tool-free Reach and Contact Point Adjust. To top it all off, a carbon blade joins our Lever Pivot Bearing technologies, so feel will remain smooth. Their best just got better.

FEATURES

• Stealth body design to complement our AXS cockpit
• Designed for the most heavy-duty braking needs
• Metallic pads come standard for more power and longer wear
• Our most powerful brake, utilizing our SwingLink and Lever Pivot Bearing for a fatigue-free ride

SPECIFICATIONS

• BRAKE TYPE - Hydraulic
• COLOR (DB) - Black Anodized
• BLADE MATERIAL - Carbon
• ORIENTATION - Front, Rear
• PAD TYPE (DISC) - Steel-backed metal sintered
• BRACKET (DISC BRAKE) - Direct mount DIR, Intl Std (140mm Rear, 160mm Front rotor) 0IS, Intl Std (160mm Rear, 180mm Front rotor) 20I, Intl Std (180mm Rear, 200mm Front rotor) 40I, Intl Std (200mm Rear rotor) 60I, Post mount (20mm bracket) 20P, Post mount (20mm spacer) 20S, Post mount (40mm bracket) 40P
• REACH ADJUST - Tool-free
• CONTACT ADJUST - Yes
• HYDRAULIC FLUID - DOT 5.1
• LEVER PIVOT - Bearing
